Mini-circuits 增值服务商
10年专注射频微波元器件产品
表面贴装和同轴外壳样式
微型 LTCC 模型，尺寸小至 0603
宽频带 MMIC Balun 高达 24 GHz
50/75 欧姆匹配变压器和匹配垫
导出Excel
| Model Number | Frequency Low (MHz) | Frequency High (MHz) | Impedance (Ω) | Impedance Ratio | Interface | Technology | Case Style | Configuration |
|---|---|---|---|---|---|---|---|---|
| Z7550-NMNF+ | DC | 2300 | 50/75 | 1.5 | CON | CORE & WIRE | H795-4 | Q |
| Z7550-NFNF+ | DC | 2500 | 50/75 | 1.5 | CON | CORE & WIRE | H795-10 | D1 |
| Z7550-FMSFDC+ | 1 | 2500 | 50/75 | 1.5 | CON | CORE & WIRE | H795-3 | Q |
| Z7550-FMSF+ | DC | 2300 | 50/75 | 1.5 | CON | CORE & WIRE | H795-3 | Q |
| Z7550-FFSF+ | DC | 2500 | 50/75 | 1.5 | CON | CORE & WIRE | H557-1 | Q |
| Z7550-FFNM+ | DC | 2300 | 50/75 | 1.5 | CON | CORE & WIRE | H795-1 | Q |
| Z7550-BMNF+ | DC | 2500 | 50/75 | 1.5 | CON | CORE & WIRE | QP1876 | Q |
| Z7550-BMBF+ | DC | 2300 | 50/75 | 1.5 | CON | CORE & WIRE | QP1876-1 | D1 |
| Z7550-BFNF+ | DC | 2500 | 50/75 | 1.5 | CON | CORE & WIRE | H795-14 | Q |
| TXA4-512HP+ | 30 | 512 | 50/12.5 | 0.25 | SMT | CORE & WIRE | PE1259 | H |
| TX16-R3T+ | 40 | 300 | 50 | 16 | SMT | CORE & WIRE | TT240 | A |
| TX9-1+ | 1 | 200 | 50 | 9 | SMT | CORE & WIRE | TT240 | C |
| TX4-62HP+ | 20 | 600 | 50 | 4 | SMT | CORE & WIRE | TT597 | H |
| TX1-R5+ | 0.8 | 500 | 50 | 1 | SMT | CORE & WIRE | TT240 | C |
| TX1-1+ | 0.3 | 400 | 50 | 1 | SMT | CORE & WIRE | TT240 | C |
| TX-2-5-1+ | 20 | 1250 | 75 | 2 | SMT | CORE & WIRE | TT240 | A |
| TTCM4-4X+ | 0.5 | 400 | 50 | 4 | SMT | CORE & WIRE | DB1627 | B |
| TTCM4-4+ | 0.5 | 400 | 50 | 4 | SMT | CORE & WIRE | DB714 | B |
| TTC2-63W+ | 100 | 6000 | 50 | 2 | SMT | CORE & WIRE | GU2939 | G |
| TTC1-682W+ | 800 | 6800 | 50 | 1 | SMT | CORE & WIRE | GU2939 | G |
| TTC1-33W-75+ | 30 | 3000 | 75 | 1 | SMT | CORE & WIRE | GU2939 | G |
| TTC1-33W+ | 4.5 | 3000 | 50 | 1 | SMT | CORE & WIRE | GU2939 | G |
| TT25-1-X65+ | 0.02 | 30 | 50 | 25 | PIN | CORE & WIRE | X65 | B |
| TT25-1-KK81+ | 0.02 | 30 | 50 | 25 | SMT | CORE & WIRE | KK81 | B |
| TT25-1+ | 0.02 | 30 | 50 | 25 | SMT | CORE & WIRE | W38 | B |
| TT16-1-KK81+ | 0.1 | 45 | 50 | 16 | SMT | CORE & WIRE | KK81 | B |
| TT4-1A-X65+ | 0.1 | 300 | 50 | 4 | PIN | CORE & WIRE | X65 | B |
| TT4-1A-KK81+ | 0.1 | 300 | 50 | 4 | SMT | CORE & WIRE | KK81 | B |
| TT4-1A+ | 0.1 | 300 | 50 | 4 | SMT | CORE & WIRE | W38 | B |
| TT4-1-X65+ | 0.05 | 200 | 50 | 3 | PIN | CORE & WIRE | X65 | B |
| TT2.5-6-KK81+ | 0.01 | 50 | 50 | 2.5 | SMT | CORE & WIRE | KK81 | B |
| TT1.5-1-X65+ | 0.075 | 500 | 50 | 1.5 | PIN | CORE & WIRE | X65 | B |
| TT1.5-1-KK81+ | 0.075 | 500 | 50 | 1.5 | SMT | CORE & WIRE | KK81 | B |
| TT1.5-1+ | 0.075 | 500 | 50 | 1.5 | SMT | CORE & WIRE | W38 | B |
| TT1-6-X65+ | 0.004 | 300 | 50 | 1 | PIN | CORE & WIRE | X65 | B |
| TT1-6-KK81+ | 0.004 | 300 | 50 | 1 | SMT | CORE & WIRE | KK81 | B |
| TT1-6+ | 0.004 | 300 | 50 | 1 | SMT | CORE & WIRE | W38 | B |
| TRS278-182-75+ | 45 | 1800 | 75 | 2.78 | SMT | CORE & WIRE | AT3278 | H |
| TRS278-122-75+ | 40 | 1250 | 75 | 2.78 | SMT | CORE & WIRE | TT2315-3 | H |
| TRS178-182-75+ | 45 | 1800 | 75 | 1.78 | SMT | CORE & WIRE | AT3278 | H |
| TRS2-252+ | 4 | 2500 | 50 | 2 | SMT | CORE & WIRE | AT577 | D |
| TRS2-1T-75+ | 5 | 1200 | 75 | 2 | SMT | CORE & WIRE | TT1618 | P1 |
| TRS1.5-182+ | 10 | 1800 | 50 | 1.5 | SMT | CORE & WIRE | TT1618 | K |
| TRS1.33-1T-75+ | 1 | 400 | 75 | 1.33 | SMT | CORE & WIRE | AT577 | A |
| TRS1-182-75+ | 10 | 1800 | 75 | 1 | SMT | CORE & WIRE | TT1618-1 | K |
| TRS1-23-75+ | 10 | 2200 | 75 | 1 | SMT | CORE & WIRE | AT577-1 | G |
| TRC1-1K122-75+ | 20 | 1250 | 75 | 1 | SMT | CORE & WIRE | GU2644 | K |
| TRC1-1-122-75+ | 5 | 1250 | 75 | 1 | SMT | CORE & WIRE | GU2644 | G |
| TMO-16-1+ | 0.3 | 120 | 50 | 16 | PIN | CORE & WIRE | A11 | C |
| TMO-13-1T+ | 0.3 | 120 | 50 | 13 | PIN | CORE & WIRE | A11 | A |
