精确的 180 度和 360 度相位控制
低插入损耗
坚固的同轴和微型表面贴装格式可供选择
导出Excel
| Model Number | Case Style | Freq. Low (MHz) | Freq. Hi (MHz) | Phase Range (deg.) Min. | Insertion Loss (dB), Typ. | Insertion Loss (dB), Max. | Control Voltage (V) | Control Bandwidth (kHz), Typ, | VSWR (:1), Typ. | VSWR (:1), Max. | PCB Layout |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SPHSA-251+ | JW1441 | 150 | 250 | 180 | 1.5 | 2.5 | 0-15 | DC-30 | 1.3 | 2.5 | 408 |
| JSPHS-2484+ | BK276 | 2150 | 2484 | 180 | 2 | 5.6 | 0-15 | DC-50 | 1.5 | 2 | 030 |
| JSPHS-1000+ | BK276 | 700 | 1000 | 160 | 1.2 | 2.3 | 0-15 | DC-50 | 1.2 | 2.6 | 030 |
| JSPHS-661+ | BK276 | 400 | 660 | 180 | 1.2 | 2.5 | 0-12 | DC-50 | 1.2 | 2.2 | 030 |
| JSPHS-446+ | BK276 | 366 | 446 | 180 | 1.2 | 2.5 | 0-12 | DC-50 | 1.2 | 1.7 | 214 |
| JSPHS-150+ | BK276 | 100 | 150 | 180 | 1.2 | 2.5 | 0-12 | DC-30 | 1.2 | 1.7 | 214 |
| JSPHS-51+ | BK276 | 36 | 54 | 180 | 1.2 | 2.5 | 0-12 | DC-50 | 1.2 | 1.8 | 030 |
| JSPHS-42+ | BK276 | 300 | 400 | 180 | 1.4 | 2.8 | 0-12 | DC-50 | 1.3 | 1.9 | 214 |
| JSPHS-23+ | BK276 | 1700 | 2000 | 180 | 2 | 3.5 | 0-15 | DC-50 | 1.5 | 2.9 | 030 |
